Doughboy Pumps & Filters

Doughboy filtration systems are engineered to provide a lifetime of reliable performance with very little maintenance.

Features

  • Uses #20 grade Silica Sand
  • AquaView’s superior sand system combines better filtration with easy-to-use operation. AquaView™ – clearly the best!
  • Seven Position Rotary Valve
  • 360° Peripheral Underdrain System – no lateral fingers to break
  • Integrated filter tank/pump base included. Separate bases also available
  • Special 10 Year Limited Warranty on Filter Tank

14" Tank

  • High Density Polyethylene 14" (O.D.) Dia. Tank
  • 7 Position Valve
  • 2 ea. 11/2" x 8 ft. & 1 ea. 11/2" x 32" pump to filter pressure hose
  • 1 sq. ft. surface area
  • Sand Capacity–80 lbs
  • Free-standing filter design
  • PowerLine™ XP Pump Series — ¾, 1½ hp
  • Filter Accessories

17" Tank

  • High Density Polyethylene 17" (O.D.) Dia. Tank
  • 7 Position Valve
  • 2 ea. 11/2" x 8 ft. & 1 ea. 11/2" x 32" pump to filter pressure hose
  • 1.4 sq. ft. surface area
  • Sand Capacity–100 lbs
  • Free-standing filter design
  • PowerLine™ XP Pump Series — ¾, 1, 1½ hp
  • Combo filter base optional
  • Filter Accessories

20" Tank

  • High Density Polyethylene 20" (O.D.) Dia. Tank
  • 7 Position Valve
  • 2 ea. 11/2" x 8 ft. & 1 ea. 11/2" x 32" pump to filter pressure hose
  • 2 sq. ft. surface area
  • Sand Capacity–150 lbs
  • Free-standing filter design
  • PowerLine™ XP Pump Series — ¾, 1½ hp
  • Filter Accessories

24" Tank

  • High Density Polyethylene 24" (O.D.) Dia. Tank
  • 7 Position Valve
  • 2 ea. 11/2" x 8 ft. & 1 ea. 11/2" x 32" pump to filter pressure hose
  • 3.14 sq. ft. surface area
  • Sand Capacity–300 lbs
  • Free-standing filter design
  • PowerLine™ XP Pump Series — 1, 1½, 2 hp
  • Injection molded, structural ABS filter ring base included
